〈1〉
〈3〉
8
Push firmly inward on the shield holding arms until
you hear them click into place.
Lower the shield past the normal upper stops, and
test operation. If the shield does not seem to work
properly, remove and gently reinstall it again.
To REMoVE/REPlACE shIElD
holDING ARMs
To take the shield holding arms off the shield,
remove shield as per previous instruction. Hold the
shield/shield holding arm as illustrated<1>. Push
〈2〉
back the lock lever at the lower bracket of the
shield holding am as illustrated <2> until it stops
releasing the lock system. Then slide the shield
holding arm upward <3>, and remove the shield as
illustrated <4>. Repeat for the other side.
〈4〉
English
