Leakage Rate
Ps[mbar]: 2.5E-3
Pe[mbar]: 7.8E-2
dt: 004:35:58
Leakage Rate [mbar l/s]:
6.3E-4
Cancel
The display shows start pressure Ps, current end pressure Pe, elapsed time dt as
well as the calculated leakage rate.
To end the rate-of-rise measurement and return to the main menu press the "OK"
key.

4.6 Settings

In order to adjust settings select item "Settings" from the main menu.
Main Menu
Start Logging
Graph
Leakage Rate
Settings
Service

4.6.1 Logging Mode

Select item "Logging Mode" in the "Settings" menu to adjust parameters for data
logger operation, i.e. logging interval and an automatic stop after a desired time
limit.
Logging Interval
Logging Mode
Logging Interval
Logging Auto Stop
Datasource
Settings
Logging Mode
Graph
Sensor
Device
Logging Interval
i
Time span between two stored
measurement values.
A lower value results in a more detailed
data capture, but also a bigger file size.
100 ms
VD810-USB-240130
41
