3 Installation

3.1 Notes for Installation

The device shall be installed by trained personnel only.
Unauthorized modifications of the instrument are not allowed!
L'appareil ne doit être installé que par du personnel qualifié.
N'apportez aucune modification non autorisée à l'appareil!
Installation location: Indoor
Temperature: +5 C ... +60
◦
Rel. humidity: max. 80% up to 30

3.2 Vacuum Connection

Dirt and damage, especially at the vacuum flange or thread
connection, have an adverse effect on the function of this vacu-
um component.
Please take account of the necessary instructions with regard
to cleanliness and damage prevention when using vacuum com-
ponents.
Remove the protective cover (is required again during maintenance work!)
Make vacuum connection via ISO KF small flange or thread connector
For small flange connection use clamps that can be opened and closed with
appropriate tools only, use sealing rings with a centering ring
Make sure that the sensor flange is connected to ground, e.g. by having
electrical contact to the grounded vacuum chamber (use metallic clamps)
The device may be mounted in any orientation. Mounting with the flange to the top,
however, can lead to early contamination and malfunction. An upright orientation
with flange to the bottom is to be preferred in order to keep particles and conden-
sates out of the sensor cell. Further the device is adjusted in the upright position
ex works.
When mounting the vacuum meter avoid forced twisting or violent
opening. This can damage the device!
C
◦
C, max. 50% at 40
◦
C, non-condensing
◦
