4.3 Start and Stop Data Logging

Your VD810 can be operated as data logger. Multiple measurements in separate
data files of type VacuGraph
mory size will be sufficient for several million data points.
By means of the VacuGraph
uploaded to a PC for plotting, analysis or further export to MS Excel (see chap-
ter 6).
Start data logging
To start data logging select item "Start Logging" in the main menu:
Main Menu
Start Logging
Graph
Leakage Rate
Settings
Service
An information screen displays the automatically allocated filename as well as the
currently set logging rate. After confirmation by the "OK"-Key data logging will start.
In the measurement menu "Logging" is displayed as operating mode.
While data logging is active the device will not be switched off au-
tomatically after 20 s or when a maximum operation time has elap-
sed! Instead a fixed timespan for data recording can optionally be
defined (see chapter 4.6.1).
Stop data logging
To stop data logging select "Stop Logging" in the main menu, then choose "OK"
and quit.
Stop Logging
!
Do you really want to stop data logging?
By pressing OK data logging will be
stopped.
OK
TM
(*.vgw) can be saved in the internal memory. Me-
TM
PC software stored measurement data can be
