2.3 Product Description

The compact vacuum meter VD810 is measuring total gas pressure in the ran-
ge 1 - 1600 mbar, additionally relative pressure in a maximum range of -1060 ...
+340 mbar.
The VD810 is equipped with a piezo-resistive ceramic sensor and temperature
compensated. Additionally the gauge operates a piezo-resistive sensor for measu-
ring ambient pressure. It must be mounted to suitable flange connectors or can be
operated directly under vacuum.
Due to the integrated data logger functionality it is possible to store multiple mea-
surements in the device. By means of the USB or optional Bluetooth interface you
can transmit the stored measurement data to a PC or record measurements online
on PC as well.
Proper Use
The VD810 serves exclusively to provide absolute and relative pressure measu-
rements in gaseous media. It may only be connected to components specifically
provided for such purpose. Please respect the admissible overload.
Improper Use
The use for purposes not covered above is regarded as improper, in particular:
connection to components which are not specified for in their operating in-
structions
connection to components containing touchable, voltage carrying parts.
In case of improper use the protection provided by the equipment may be impai-
red, no liability or warranty will be accepted for claims arising.
The user bears the responsibility with respect to the used process media.
The equipment is intended for integration in an end-use system. Suitability of the
final combination shall be evaluated in the end-use.
The device is not designed for use in corrosive gas atmosphere.
Aggressive media such as halogenides, carbon or oxygen plasma
can reduce sensor life-time!
Dust, oil or condensing vapours will affect sensor performance and
may cause malfunction!
