7.2

Mounting / Dismounting, Operating Position

7.2.1 Assembly
To prevent soiling of the plug pins, use a suitable closing cover
(see "Accessories and Spare parts").
Operating position
• Store in an unplugged state, suspended with the contacts pointing downward.
7.3

Installation

Danger due to live components!
Risk of severe injuries!
• All connections and wiring must be disconnected from the power
• Secure the connections against unauthorized switching.
Explosion hazard!
Risk of injuries and material damage!
• Select suitable cables to ensure that the maximum permissible
• When using the core end sleeves, attach them using a suitable
• Observe the insulating capacity and separation distances between
• Use only separately tested cable glands and stopping plugs with
• The conductor insulation must reach to the terminal.
• Do not damage the conductor (e.g. nicking) when stripping it.
• Always connect the protective conductor.
Two conductors can be installed under one connection terminal. The material
and cross-section of both conductors must be identical. The conductors can
be connected without any special preparations.
218039 / 8571616300
2016-06-02·BA00·III·en·01
supply.
conductor temperatures are not exceeded.
tool.
intrinsically safe and non-intrinsically safe circuits according to
EN 60079-14, section 12.
EC Type Examination Certificate.
Mounting and Installation
WARNING
DANGER
SolConeX Plug, 32 A
Series 8571/12
