PRODUCT INTRODUCTION
Typical installation scene
Domestic Water In
Domestic
Water Out
1
6
1. Indoor unit
2. Outdoor unit
3. Refrigerant pipe and connecting cable
4. Water pipe
5. Ground wire to ground outdoor unit to prevent electrical shocks.
6. Remote controller
7. Water pipe for DHW tank
*The shape of products can be changed according to the model capacity and type.
7
4
Water Water
Out In
PRODUCT INTRODUCTION
3
2
5
