Emptying And Disassembling The System - Qufora IrriSedo Klick Gebrauchsanweisung

EN

Emptying and disassembling the system

21. Click-off the used catheter into the grey pouch by pressing the purple button. Hold
the tube upwards to prevent water spillage. The pouch can be folded and sealed
using the sticky area, then disposed of in household waste.
22. Place the system in the sink for emptying, separating and cleaning.
23. Separate the parts by clicking and pulling the connectors apart.
24. Empty the water from the system. To empty the control unit and the pump, turn
the control unit to position 1 and let the water run out through the control unit
(24a). To empty the water bag, open the valve on the water bag and let the water
run through the tube (24b) or open the lid on the water bag and empty the bag
through the opening (24c).
21
24c
Cleaning and storing after use
25. Clean the outside of the click tube, the water bag and tube with mild soap and
water, rinse and dry.
26. Hang the system to dry with the water bag lid and the valve on the water bag tube
open and leave the control unit in position 1.
27. Wash and dry your hands.
28. Store the product out of direct sunlight in a dry and ventilated place between 0° C
and 30° C.
8
23
Open
valve
24a 24b
