Qufora IrriSedo Klick Gebrauchsanweisung Seite 6

EN
Filling the system with water
8. Open the catheter pouch at the perforated line. Whilst the catheter is still in
the pouch connect the click tube to the catheter - when you hear a click, it is
connected. Take the catheter out without touching the hydrophilic coating.
9. Attach the empty pouch to a surface using the sticky area on the back of the
pouch.
10. Turn the control unit to position 1.
11. Hold the pump with the control unit pointing upwards (11a) and open the valve on
the water bag tube (11b). Squeeze the pump until it is full of water so that no air is
left and water comes out of the catheter (11c).
12. Pause the system by turning the control unit to the dot position between 1 and 2.
13. Hold the catheter under the tap or dip it in water up to its base for a few seconds
to activate the hydrophilic coating. The system is now ready for use.
8
Open
valve
11b
6
Sticky
area
9
11c
10
12
11a
A few
seconds
13
