02FE
2
0300
64
Copy State Machine 9
0340
4
0344
1
0345
1
0346
2
0348
64
Copy State Machine 10
0388
4
038C
1
038D
1
038E
2
0390
64
29.02.2024
S-DIAS PROFINET I/O-SLAVE
r
reserved
r/w
Datenregister 8
r/w
Adressregister 9
Status/Control 9
Bit 0
Write Enable (0 = Read Enable)
Bit 1
Busy (nur lesbar)
Bit 2
AutoIncrement Enable
r/w
Bit 3
Sync0 Start
Bit 4
Sync1 Start
Bit 5
IRQStart
Bit 6
Address Start
Bit 7
SW Start
r/w
Access size 9
r
Reserved
r/w
Datenregister 9
r/w
Adressregister 10
Status/Control 10
Bit 0
Write Enable (0 = Read Enable)
Bit 1
Busy (nur lesbar)
Bit 2
AutoIncrement Enable
r/w
Bit 3
Sync0 Start
Bit 4
Sync1 Start
Bit 5
IRQStart
Bit 6
Address Start
Bit 7
SW Start
r/w
Access size 10
r
Reserved
r/w
Datenregister 10
IPN 021-1
Seite 31
