Emerson AVENTICS IO-Link AF2 Betriebsanleitung Seite 11

AVENTICS specific
Index dec Name Format
(hex) (offset)
420 Display unit UInt
(0x1A4) mass flow
421 Display unit gas UInt
(0x1A5) speed
422 Display unit vol- UInt
(0x1A6) ume
423 Display unit vol- UInt
(0x1A7) ume flow
424 Display unit UInt
(0x1A8) mass
425 Display unit en- UInt
(0x1A9) ergy
426 Display unit tem- UInt
(0x1AA) perature
427 Display unit UInt
(0x1AB) pressure
428 Switch off dis- UInt
(0x1AC) play
429 Rotate display UInt
(0x1AD)
430 Screensaver UInt
(0x1AE)
431 Display bright- UInt
(0x1AF) ness
432 Display pin UInt
(0x1B0)
433 Display 1 top UInt
(0x1B1)
434 Display 1 bot- UInt
(0x1B2) tom
AVENTICS™ IO-Link AF2 | R412027828-BAL-001-AB | English
Lengt Ac- Default value Value
h cess range
8 bits rw 0 = kg/h
1 = g/s
2 = kg/min
8 bits rw 0 = m/s
1 = fps
8 bits rw 0 = m³
1 = l
2 = ft³
8 bits rw 0 = m³/h
1 = m³/min
2 = l/s
3 = l/min
4 = ft³/s
5 = ft³/min
8 bits rw 0 = kg
8 bits rw 0 = kWh
8 bits rw 0 = °C
1 = °F
8 bits rw 0 = bar
1 = psi
8 bits rw 0 = off
1 = 1min
2 = 2min
5 = 5min
10 = 10min
30 = 30min
60 = 60min
8 bits rw 0 = 0°
1 = 90°
2 = 180°
3 = 270°
8 bits rw 0 = off
1 = 1min
2 = 2min
5 = 5min
10 = 10min
30 = 30min
60 = 60min
8 bits rw 2 = 40%
7 = 60%
10 = 80%
15 = 100%
16 bits rw 0 ... 9999 Pin to protect the
configuration,
0000 ==> no pin
assigned
8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
AVENTICS specific
Com- Index dec Name
ment (hex)
[unit]
435 Display 2 top
(0x1B3)
436 Display 2 bot-
(0x1B4) tom
437 Display 3 top
(0x1B5)
438 Display 3 bot-
(0x1B6) tom
439 Display history
(0x1B7)
440 Flow simulation
(0x1B8)
Format Lengt Ac- Default value
(offset) h cess
UInt 8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
UInt 8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
UInt 8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
UInt 8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
UInt 8 bits rw 0 = mass flow
1 = flow speed
2 = volume
3 = volume flow
4 = mass
5 = energy
6 = temperature
7 = pressure
UInt 8 bits rw 0 = 0%
10 = 10%
20 = 20%
30 = 30%
40 = 40%
50 = 50%
60 = 60%
70 = 70%
80 = 80%
90 = 90%
100 = 100%
255 = simulation off
Value Com-
range ment
[unit]
11
