Emerson AVENTICS IO-Link AF2 Betriebsanleitung Seite 12

AVENTICS specific
Index dec Name Format
(hex) (offset)
441 Temperature UInt
(0x1B9) simulation
442 Pressure simula- UInt
(0x1BA) tion
443 Flow medium UInt
(0x1BB)
444 Reference condi- UInt
(0x1BC) tions for the flow
445 Customer-spe- Float
(0x1BD) cific reference
pressure
446 Customer-spe- Float
(0x1BE) cific reference
temperature
447 Input zero point Float
(0x1BF) offset for flow
448 Input low flow Float
(0x1C0) cut-off
449 Input smoothing UInt
(0x1C1) filter for flow
450 Flow measuring UInt
(0x1C2) mode
453 Input zero point Float
(0x1C5) offset for pres-
sure
AVENTICS™ IO-Link AF2 | R412027828-BAL-001-AB | English
Lengt Ac- Default value Value
h cess range
8 bits rw 0 = 0%
10 = 10%
20 = 20%
30 = 30%
40 = 40%
50 = 50%
60 = 60%
70 = 70%
80 = 80%
90 = 90%
100 = 100%
255 = simulation off
8 bits rw 0 = 0%
10 = 10%
20 = 20%
30 = 30%
40 = 40%
50 = 50%
60 = 60%
70 = 70%
80 = 80%
90 = 90%
100 = 100%
255 = simulation off
8 bits rw 0 = air
1 = nitrogen
2 = carbon dioxide CO2
4 = argon
8 bits rw 0 = ISO8778
1 = ISO6358
2 = DIN1343
3 = DIN1945-1
4 = ISO1217
5 = ISO2533
6 = customer-specific
4 rw -1.0 ... 16.0
bytes
4 rw -20.0 ... 60.0
bytes
4 rw -10.0 ... 10.0
bytes
4 rw 0.0 ... 10.0
bytes
8 bits rw 0 = off
1 = 100ms
2 = 200ms
5 = 500ms
10 = 1sec
20 = 2sec
50 = 5sec
100 = 10sec
8 bits rw 0 = standard
4 rw -0.5 ... 0.5 [bar]
bytes
AVENTICS specific
Com- Index dec Name
ment (hex)
[unit]
454 Input smoothing
(0x1C6) filter for pressure
458 Input smoothing
(0x1CA) filter for temper-
ature
481 Signal quality 1
(0x1E1) (sensor robust-
ness)
482 Signal quality 2
(0x1E2)
483 Signal quality 3
(0x1E3)
484 Signal quality 4
(0x1E4)
485 PowerUp
(0x1E5) counter
486 Sensor power
(0x1E6) supply
487 Sensor tempera-
(0x1E7) ture
488 Mass flow statis-
(0x1E8) tics
1 (0x01) Minimum
2 (0x02) Maximum
3 (0x03) Average value
489 Flow speed sta-
(0x1E9) tistics
490 Volume flow sta-
(0x1EA) tistics
491 Temperature
(0x1EB) statistics
492 Pressure statis-
(0x1EC) tics
493 Statistics dura-
(0x1ED) tion since reset
496 Counter status
(0x1F0) since reset
502 Active messages Record
(0x1F6)
1 (0x01) Message 1 num-
ber
2 (0x02) Message 1 level
3 (0x03) Message 1 de-
scription
4 (0x04) Message 2 num-
ber
5 (0x05) Message 2 level
Format Lengt Ac- Default value
(offset) h cess
UInt 8 bits rw 0 = off
1 = 100ms
2 = 200ms
5 = 500ms
10 = 1sec
20 = 2sec
50 = 5sec
100 = 10sec
UInt 8 bits rw 0 = off
1 = 100ms
2 = 200ms
5 = 500ms
10 = 1sec
20 = 2sec
50 = 5sec
100 = 10sec
UInt 8 bits ro 0 ... 100
UInt 8 bits ro 0 ... 100
UInt 8 bits ro 0 ... 100
UInt 8 bits ro 0 ... 100
UInt 32 bits ro
Float 4 ro [V]
bytes
Float 4 ro (Parameter in 0.1°C) [°C]
bytes
Record 12 ro
bytes
Bit (64) 4 ro
bytes
Bit (32) 4 ro
bytes
Bit (0) 4 ro
bytes
Record 12 ro See index 488
bytes
Record 12 ro See index 488
bytes
Record 12 ro See index 488
bytes
Record 12 ro See index 488
bytes
UInt 32 bits ro See index 488
UInt 32 bits ro Reset process data rVolume, rMass,
rEnergy
140 ro 4 active messages with highest prior-
bytes ity
Bit 16 bits ro
(1104)
Bit 8 bits ro 0 = no message
(1096)
1 = information
2 = warning
3 = error
Bit (840) 32 ro
bytes
Bit (824) 16 bits ro
Bit (816) 8 bits ro 0 = no message
1 = information
2 = warning
3 = error
Value Com-
range ment
[unit]
[%]
[%]
[%]
[%]
12
