Operation - EuroLite LED FE-6 Bedienungsanleitung

1 Setting up your new show laser only takes a minute. Simply connect the mains cable provided and insert the
mains plug it into a grounded outlet. To turn on the device, press the POWER switch. The fan and the motors
will start.
2 You're ready to go: Select the desired operating mode with the AUTO/SOUND switch and the light and laser
beams will dance through the room. In AUTO mode, the effects will run automatically. In SOUND mode, the
effects will be flashing to the rhythm of the music. Note: The LEDs and the laser will be switched off after a few
seconds if the volume is too low or if there is no sufficient bass beat.
3 You can use the remote control to control each effect conveniently from a distance. Simply press [
switch the LEDs and the laser beams on and off and adjust the desired settings for the disco ball, strobe LEDs
and laser diodes.
Switches between auto and music mode. Set the microphone sensitivity for music mode with the
SEN+ and SEN- buttons.
Switches the strobe LEDs on and off. Set the flash rate with the SPEED+ and SPEED- buttons.
Switches the laser diodes on and off. Set the laser color with the COLOR button and the speed with
the SPEED button.
Switches the disco ball on and off. Set the color with the Red, Green, Blue and White buttons.
Press Jump for color change and Gradual for color fade. Pulse activates a flash feature and Flash
a strobe feature.
4 After operation, switch off the device with the POWER switch. Remove the battery inside the remote control if
the device is not used for a longer period.
Notes
• When actuating a button, always hold the remote control in the direction of the sensor at the unit's front. There
must be visual connection between the remote control and the sensor.
• The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the foil
from the battery support on the rear side of the remote control. Otherwise operation of the remote control is not
possible.
• If the range of the remote control decreases, replace the battery. For this purpose, on
the rear side of the remote control press the small bar with the groove to the right and at
the same time remove the battery support. For operation, one 3 V button cell type CR
2025 is required. When inserting, pay attention that the positive pole of the button cell
shows upwards in the support.

OPERATION

21 • EN
