We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents! Before cleaning, disconnect the device from the power supply. Make sure that no liquids can
enter the device.
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are only
to be carried out by authorized dealers.
Should you need any spare parts, please use genuine parts. If defective, please dispose of the unusable device in
accordance with the current legal regulations. Should you have further questions, please contact your dealer.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating. Before replacing
the fuse, unplug mains lead.
Procedure:
• Step 1: Open the fuse holder on the rear panel with a fitting screwdriver.
• Step 2: Remove the old fuse from the fuse holder.
• Step 3: Install the new fuse in the fuse holder.
• Step 4: Replace the fuse holder in the housing.
Power supply:
Power consumption:
Fuse:
Laser classification:
Laser modules:
Color LEDs:
Strobe LEDs:
Sound control:
Maximum ambient temperature T
Maximum housing temperature T
Dimensions (LxWxH):
Weight:
Specifications are subject to change without notice due to product improvements.
Accessories
No. 59006856
No. 59006858
No. 58010310
No. 58010342
CLEANING AND MAINTENANCE
TECHNICAL SPECIFICATIONS
100-240 V AC, 50/60 Hz
32 W
T0.5A/250V
3R
red (64 mW, 532 nm), green (54 mW, 650 nm)
4 (R, G, B, W), 1 W each
8, 1 W each
via built-in microphone
:
45° C
a
:
55° C
c
250 x 180 x 195 mm
1.5 kg
EUROLITE TPC-10 Coupler, silver
EUROLITE TPC-10 Coupler, black
EUROLITE Safety bond A 3x600mm up to 5kg, silver
EUROLITE Safety bond A 3x600mm up to 5kg, black
22 • EN
