spectro2profiler
8 Technical Data
Color Measurement
Geometry
Aperture size
Spectral range
Repeatability
Reproducibility
Color systems
Color differences
Indices
Illuminants
Observer
Gloss Measurement
Aperture size
Meas. range
2D Reflectivity Measurement
Aperture size
Measurement range
Spatial resolution
Repeatability
Reproducibility
12
45°c:0°
Diameter 25 mm
400 - 700 nm, 10 nm resolution
0.01 ∆E94 (10 readings on white)
0.1 ∆E94 (average of 12 BCRA tiles)
CIELab/Ch, Lab(h), XYZ, Yxy
∆E*, ∆E(h), ∆E94, ∆ECMC, ∆E99, ∆E2000, ∆E2000PF, ∆E6175
YI , YI , WI
E313 D1925
Opacity, Metamerism, Gray Scale
A, C, D50, D55, D65, D75, F2, F6, F7, F8, F10, F11, UL30
2°, 10°
25 × 15 mm
0 - 20 GU
20 - 100 GU
15 × 15 mm
0 - 500 000,
technical performance guaranteed within 0 - 2500
60 µm
(1)
0.5 % (10 readings on structure reference standard)
(1)
1.0 % (on structure reference standard)
, WI , WI ,
E313 CIE Berger
Repeatability
± 0.1 GU
± 0.2 GU
BYK-Gardner GmbH
Reproducibility
± 0.2 GU
± 1.0 GU
283 025 449 - 2305
