spectro2profiler BYK-Gardner GmbH Table of Contents English ....................Deutsch..................... Français..................... Italiano ..................... Español ..................... 中文 ....................日本語 ....................Русский..................... 283 025 449 - 2305...
BYK-Gardner GmbH spectro2profiler 1 System Description The system consists of instrument, calibration and test tiles and software for data transfer and analysis. • Connect instrument (1) with PC via USB cable (2). • When connecting for the first time, instrument is automatically turned on. •...
spectro2profiler BYK-Gardner GmbH 2 Software Installation 1. Download zip-file from: https://www.byk-instruments.com/spectro2profiler 2. Save the file into a new folder and extract the complete archive. 3. Right mouse click on “install.exe” and select option “Run as administrator”. 4. Follow the setup instructions on the screen. The software includes two packages: •...
BYK-Gardner GmbH spectro2profiler 3 Main Menu The following symbols are displayed by default. Difference Absolute Compare standard and sample. Res- Take absolute measurements ults are saved automatically. without comparing to a standard. Results are saved automatically. Quick Check Browse Perform quick evaluations without View and delete measurement data.
spectro2profiler BYK-Gardner GmbH 4 Measurement Parameters Go to Configuration > Measurement Parameters. 2D/3D Settings: Select algorithm to be Gloss: Turn gloss measurement and / or used - Leather-Like, Leather-Inverted, difference measurement for gloss on or Coarse Paint, Fine. Details see separate off.
BYK-Gardner GmbH spectro2profiler 5 Instrument Calibration The instrument comes with a calibration standard and test standard for color and gloss. Each tile has a dedicated serial number matching your instrument. Use these tiles to mon- itor the performance of your instrument. The instrument will guide you through the pro- cedure.
spectro2profiler BYK-Gardner GmbH 6 Difference Measurement Search for matching standards, create new standards and compare samples to existing standards. Results are automatically saved. 1. Select existing standard from list (1) or add a new standard. 2. To add a new standard, tap on + symbol (2). 3.
BYK-Gardner GmbH spectro2profiler 7 Absolute Measurement and Quick Check Take measurements without comparison to a standard. Results are automatically saved. 1. Place instrument on 1 sample. 2. Click on Measure or press Operate button. 3. Sample is measured and automatically saved. 4.
BYK-Gardner GmbH spectro2profiler 1 Systembeschreibung Das System besteht aus Messgerät, Kalibrier- und Test-Standards und Software für Daten- transfer und -analyse. • Gerät (1) über das USB-Kabel mit dem PC verbinden (2). • Mit dem erstmaligen Verbinden schaltet sich das Gerät automatisch ein. •...
spectro2profiler BYK-Gardner GmbH 2 Software Installation 1. ZIP-Datei herunterladen von: https://www.byk-instruments.com/spectro2profiler 2. Datei in einem neuen Ordner speichern und das ZIP-Archiv komplett entpacken. 3. Mit der rechten Maus-Taste auf “install.exe” klicken und die Option “Als Adminis- trator ausführen” wählen. 4. Den Installationsanweisungen auf dem Bildschirm folgen. Die Software umfasst zwei Pakete: •...
BYK-Gardner GmbH spectro2profiler 3 Hauptmenü Die folgenden Symbole werden standardmäßig angezeigt. Differenz Absolut Standard und Probe vergleichen. Er- Absolutmessung ohne Standard gebnisse werden automatisch ge- durchführen. Ergebnisse werden au- speichert. tomatisch gespeichert. Quick-Check Datenansicht Schneller Vergleich, ohne Messwerte Anzeigen und Löschen von Messda- zu speichern.
spectro2profiler BYK-Gardner GmbH 4 Messparameter Einstellungen > Messparameter auswählen. 2D/3D-Einstellungen: Algorithmus für die Glanz: Glanzmessung und / oder Differenz- Messung wählen - Leather-Like, Leather- messung für Glanz ein- oder ausschalten. Inverted, Coarse Paint, Fine. Details sie- he separates Glossar. 2D/3D-Skalen: Auswahl der zu messenden Lichtart: Auswahl der Normlichtart.
BYK-Gardner GmbH spectro2profiler 5 Kalibrierung Die Lieferung umfasst einen Kalibrierstandard und je einen Teststandard für Farbe und für Glanz. Jeder Teststandard hat eine Seriennummer, die zum Gerät passt. Mit diesen Kacheln prüfen, ob das Gerät korrekt misst. Das Gerät führt durch die Prüfung. 1.
spectro2profiler BYK-Gardner GmbH 6 Differenzmessung Nach passenden Standards suchen, neue Standards anlegen und Proben mit Standards ver- gleichen. Die Ergebnisse werden automatisch gespeichert. 1. Bestehenden Standard wählen (1) oder neuen Standard anlegen. 2. Zum Anlegen eines neuen Standards auf das Plus-Symbol + (2) tippen. 3.
BYK-Gardner GmbH spectro2profiler 7 Absolutmessung und Quickcheck Messungen durchführen, ohne zu einem Standard zu vergleichen. Die Ergebnisse werden automatisch gespeichert. 1. Messgerät auf die erste Probe stellen. 2. Auf Messen (3) tippen oder Taste Operate drücken. 3. Die Probe wird gemessen und automatisch gespeichert. 4.
Seite 24
spectro2profiler BYK-Gardner GmbH Table des matières Description du système ......................Installation du logiciel........................ Menu principal ..........................Paramètres de mesure ........................ Calibrage instrument ........................Mesure en différence........................Mesure en absolu et mesure rapide ..................Données techniques........................283 025 449 - 2305...
BYK-Gardner GmbH spectro2profiler 1 Description du système Le système se compose d'un instrument, des étalons de référence et de calibrage, ainsi qu'un logiciel pour le transfert et l'analyse des données. • Connecter l'instrument (1) au PC avec le câble USB (2). •...
spectro2profiler BYK-Gardner GmbH 2 Installation du logiciel 1. Télécharger le fichier zip depuis: https://www.byk-instruments.com/spectro2profiler 2. Sauvegarder le fichier dans un nouveau répertoire et faire l'extraction de l'archive. 3. Faire un clic droit de la souris sur le fichier “install.exe” et sélectionner l'option “Exé- cuter en tant qu'administrateur”.
BYK-Gardner GmbH spectro2profiler 3 Menu principal Les symboles suivants sont affichés par défaut. Différence Absolu Comparer le standard et l'échan- Prendre des mesures en absolu sans tillon. Les résultats sont enregistrés comparer à un standard. Les résul- automatiquement. tats sont enregistrés automatique- ment.
spectro2profiler BYK-Gardner GmbH 4 Paramètres de mesure Aller dans Configuration > Paramètres de mesure. Réglages 2D/3D: Sélectionner l'algo- Brillant: Activer ou désactiver la mesure rythme: Leather-Like, Leather-Inverted, de la brillance et/ou la mesure de la diffé- Coarse Paint, Fine. Pour les détails voir le rence pour la brillance.
BYK-Gardner GmbH spectro2profiler 5 Calibrage instrument L'instrument est livré avec standard de calibrage et un étalon de test couleur et de brillance. Chaque standard a un numéro de série dédié correspondant à votre instrument. Utiliser ces standards pour surveiller les performances de votre instrument. L'instrument vous guidera tout au long de la procédure.
spectro2profiler BYK-Gardner GmbH 6 Mesure en différence Rechercher des standards correspondants, créer de nouveaux standards et comparer des échantillons avec des standards existants. Les résultats sont automatiquement enregistrés. 1. Sélectionner le standard dans la liste (1) ou ajouter un nouveau standard. 2.
BYK-Gardner GmbH spectro2profiler 7 Mesure en absolu et mesure rapide Prendre des mesures sans comparaison avec un standard. Les résultats sont automatique- ment enregistrés. 1. Placer l'instrument sur le 1 échantillon. 2. Cliquer sur Mesure ou presser le bouton Operate. 3.
BYK-Gardner GmbH spectro2profiler Mesure de la structure 3D (Cs, Ca) Taille d'ouverture 15 × 15 mm Plage de mesure Taille de cellule (Cs): 0 - 255 mm Amplitude de cellule (Ca): 2 µm - 2 mm (perçu) Résolution spatiale 60 µm Résolution en hau- 1 - 2 µm teur...
Seite 34
spectro2profiler BYK-Gardner GmbH Indice Descrizione del Sistema......................Installazione del Software ......................Menu Principale........................... Parametri di Misura ........................Calibrazione dello Strumento ....................Misura in Differenza ........................Misura in Assoluto e Misura Veloce ..................Dati Tecnici ..........................283 025 449 - 2305...
BYK-Gardner GmbH spectro2profiler 1 Descrizione del Sistema Il sistema consiste di strumento, piastre di calibrazione e di controllo e software per il tra- sferimento e l'analisi dei dati. • Connettere lo strumento (1) al PC con il cavo USB (2). •...
spectro2profiler BYK-Gardner GmbH 2 Installazione del Software 1. Scaricare il file-zip da: https://www.byk-instruments.com/spectro2profiler 2. Salvare il file in una nuova cartella e estrarre l'archivio completo. 3. Con il tasto destro del mouse cliccare su “Install.exe” e selezionare “Esegui come amministratore”. 4.
BYK-Gardner GmbH spectro2profiler 3 Menu Principale I seguenti simboli sono visualizzati di default. Differenza Assoluti Confronta campione e standard. I ri- Effettua misure in assoluto senza sultati vengono salvati automatica- confronto. I risultati vengono salvati mente. automaticamente. Misura veloce Navigazione Effettua misure veloci senza salvare.
spectro2profiler BYK-Gardner GmbH 4 Parametri di Misura Andare in Configurazione > Parametri di misura. Impostazioni 2D/3D: Seleziona l'algorit- Gloss: Attiva o disattiva la misura del gloss mo: Leather-Like, Leather-Inverted, e/o la misura della differenza. Coarse Paint, Fine. Per i dettagli vedere il Glossario separato.
BYK-Gardner GmbH spectro2profiler 5 Calibrazione dello Strumento Lo strumento viene con uno standard di calibrazione e standard di controllo per colore e gloss. Ciascuna piastra ha un numero di serie dedicato che coincide con lo strumento. Usa- re queste piastre per controllare la performance dello strumento. Lo strumento guiderà durante la procedura.
spectro2profiler BYK-Gardner GmbH 6 Misura in Differenza Per cercare gli standard, creare nuovi standard e confrontare campioni a standard esistenti. I risultati vengono salvati automaticamente. 1. Scegliere lo standard esistente dalla lista (1) o aggiungere un nuovo standard. 2. Per aggiungere un nuovo standard cliccare sul simbolo + (2). 3.
BYK-Gardner GmbH spectro2profiler 7 Misura in Assoluto e Misura Veloce Misura in Assoluto Effettua misure senza confronto con uno standard. I risultati vengono salvati automatica- mente. 1. Posizionare lo strumento sul 1° campione. 2. Cliccare su Misura o premere il tasto Operate. 3.
BYK-Gardner GmbH spectro2profiler Misura della struttura 3D (Cs, Ca) Dimensione apertu- 15 × 15 mm Range di misura Cell size (Cs): 0 - 255 mm Cell amplitude (Ca): 2 µm - 2 mm (percepito) Risoluzione spaziale 60 µm Risoluzione altezza 1 - 2 µm Ripetibilità...
Seite 44
spectro2profiler BYK-Gardner GmbH Tabla de contenidos Descripción del sistema ......................Instalación del software ......................Menú principal ..........................Parámetros de medición......................Calibración del instrumento ...................... Medida de diferencias ........................ Medición absoluta y medición rápida ..................Datos técnicos ..........................283 025 449 - 2305...
BYK-Gardner GmbH spectro2profiler 1 Descripción del sistema El sistema consiste de instrumento, patrones de calibración y control y software para trans- ferencia de datos y análisis. • Conectar el instrumento (1) al PC via cable USB (2). • Cuando se conecta por primera vez, el instrumento se pone en marcha automatica- mente.
spectro2profiler BYK-Gardner GmbH 2 Instalación del software 1. Descargue el archivo zip-file de: https://www.byk-instruments.com/spectro2profiler 2. Guarde el archivo en una nueva carpeta y extraiga el archivo completo. 3. Presionando el botón derecho del ratón “install.exe” y seleccione la opción “Ejecutar como administrador”.
BYK-Gardner GmbH spectro2profiler 3 Menú principal Los siguientes símbolos se mostrarán por defecto. Diferencia Absoluto Compara el patrón y la muestra. Los Hacer mediciones en valor absoluto Resultados se guardan automatica- sín comparar a un patrón. Los resul- mente. tados se guardan automaticamente. Medición rápida Navegar Hacer mediciones rápidas sin guar-...
spectro2profiler BYK-Gardner GmbH 4 Parámetros de medición Vaya a Configuración > Parámetros de Medición. Ajustes 2D/3D : Selección de algoritmo: Brillo: Active o desactive la medición y la Similar al cuero, Cuero-Invertido, Pin- diferencia del brillo. tura rugosa, Fino. Ver los detalles por se- parado en el Glosario.
BYK-Gardner GmbH spectro2profiler 5 Calibración del instrumento El instrumento viene con un patrón de calibration uno de comprobación y uno de brillo. Cada patrón tiene un número de serie que corresponde al instrumento. Use estos patrones para monitorizar el funcionamiento de su instrumento. El instrumento le guiará a traves del procedimiento.
spectro2profiler BYK-Gardner GmbH 6 Medida de diferencias Busqueda de patrones cercanos , crear nuevos patrones y compare muestraa a patrones ya existentes. Los Resultados se guardan automaticamente. 1. Seleccione un patrón de la lista (1) o añada uno nuevo. 2. Par añadir un nuevo patrón click en el + símbolo (2). 3.
BYK-Gardner GmbH spectro2profiler 7 Medición absoluta y medición rápida Medición absoluta Hacer mediciones sín comparar al patrón. Los Resultados se guardan automaticamente. 1. Colocar el instrumento en la primera muestra. 2. Click en Medir o presionar el botón Operate. 3. La Muestra se mide y se guarda automaticamente. 4.
spectro2profiler BYK-Gardner GmbH 8 Datos técnicos Medición de color Geometría 45°c:0° Tamaño de apertura Diámetro 25 mm Rango Espectral 400 - 700 nm, resolución 10 nm Repetibilidad 0.01 ∆E94 (10 lecturas sobre el blanco) Reproducibilidad 0.1 ∆E94 (media de 12 patrones BCRA ) SIstemas de Color CIELab/Ch, Lab(h), XYZ, Yxy Diferencias de color...
BYK-Gardner GmbH spectro2profiler Medición de estructura 3D (Cs, Ca) Tamaño de apertura 15 × 15 mm Rango de medición Tamaño de celda (Cs): 0 - 255 mm Amplitud de celda (Ca): 2 µm - 2 mm (percivida) Resolución Espacial 60 µm Resolución en altura 1 - 2 µm Repetibilidad...
Seite 73
BYK-Gardner GmbH spectro2profiler 3D 形状測定 (Cs, Ca) 測定口径 15 × 15 mm 測定レンジ セルサイズ (Cs): 0 - 255 mm セル振幅 (Ca): 2 µm - 2 mm 空間解像度 60 µm 最大解像度 1 - 2 µm 繰り返し性 2% (ストラクチャー基準スタンダード 10回測定) 精度 5% (ストラクチャー基準スタンダードにて) 一般データ...
Seite 74
spectro2profiler BYK-Gardner GmbH Содержание Описание системы........................Установка программы ......................... Главное меню ..........................Параметры измерений......................... Калибровка прибора........................Измерение отличий ........................Абсолютные и быстрые измерения ................... Технические характеристики....................... 283 025 449 - 2305...
BYK-Gardner GmbH spectro2profiler 1 Описание системы Система состоит из прибора, калибровочных и проверочных пластин и программного обеспечения для переноса и анализа данных на ПК. • Присоединить прибор (1) к ПК при помощи USB кабеля (2). • При первом присоединении прибор включится автоматически. •...
spectro2profiler BYK-Gardner GmbH 2 Установка программы 1. Загрузить zip-файл по ссылке: https://www.byk-instruments.com/spectro2profiler 2. Сохранить файл в новой папке на ПК и полностью извлечь архив. 3. Правой клавишей мыши нажать на “install.exe” и выбрать опцию “Run as administrator”. 4. Следовать инструкциям по установке на экране. Программа...
BYK-Gardner GmbH spectro2profiler 3 Главное меню По умолчанию на экране отображаются следующие символы. Отличия Абсолютные измерения Сравнение образца с эталоном. Ре- Проведение измерений абсолютных зультаты сохраняются автоматиче- значений образца без сравнения с ски. эталоном. Результаты сохраняются автоматически. Быстрое измерение Память Проведение...
spectro2profiler BYK-Gardner GmbH 4 Параметры измерений Перейти к Конфигурация > Параметры измерений. 2D/3D установки: Выбрать алгоритм: Блеск: Включить измерения блеска и / или Leather-Like, Leather-Inverted, Coarse измерения отличий для включения или вы- Paint, Fine. Детали см. дополнительно в ключения блеска. Глоссарий.
BYK-Gardner GmbH spectro2profiler 5 Калибровка прибора Прибор поставляется с калибровочным стандартом и проверочным стандартом для цвета и блеска. Каждая пластина имеет серийный номер, соответствующий прибору. Исполь- зуйте данные стандартные пластины для контроля работы прибора. Встроенные подсказки помогу пройти данную процедуру. 1.
spectro2profiler BYK-Gardner GmbH 6 Измерение отличий Найти подходящие стандарты, создать новые стандарты и сравнить образцы с существу- ющими стандартами. Результаты сохраняются автоматически. 1. Выбрать существующий стандарт из списка (1) или добавить новый стандарт. 2. Для добавления нового стандарта нажать на символ + (2). 3.
BYK-Gardner GmbH spectro2profiler 7 Абсолютные и быстрые измерения Абсолютное измерение Измерения без сравнения со стандартом. Результаты сохраняются автоматически. ый 1. Поместить прибор на 1 образец. 2. Нажать на Измерить или на рабочую кнопку Operate. 3. Образец измерен и автоматически сохранен. 4.
BYK-Gardner GmbH spectro2profiler Измерение 3D структуры (Cs, Ca) Размер апертуры 15 × 15 мм Диапазон измерения Размер ячейки (Cs): 0 - 255 мм Амплитуда ячейки (Ca): 2 мкм - 2 мм (воспринимаемая) Пространственное 60 мкм разрешение Разрешение по вы- 1 - 2 мкм соте...
Seite 84
Download your manuals from: https://www.byk-instruments.com/p/7300 Download your software from: https://www.byk-instruments.com/spectro2profiler BYK-Gardner GmbH Lausitzer Strasse 8 82538 Geretsried Germany Tel +49 08171 3493-0 Fax +49 08171 3493-140 info.byk.gardner@altana.com www.byk-instruments.com...
