Modbus Settings (2001...2006)

Modbus Modbus No.of
Register Address Byte
2001 2000
2002 2001
2003 2002
2004 2003
2005 2004
2006 2005
Analog Scaling Settings (2007...2011)
Modbus Modbus No.of
Register Address Byte
2007 2006
2009 2008
2011 2010
Modbus installation, Modbus settings and further information refer to the manual CS
Instruments "Modbus Installation and Operating Instructions FA 5xx sensors"
Data Type
2 UInt16 Modbus ID
2 UInt16 Baudrate
2 UInt16 Parity
2 UInt16 Number of Stopbits
2 UInt16 Word Order
2 UInt16 Modbus Enabled
Data Type
4 UInt32 Output Value
4 float 4mA Scale Low
4 float 20mA Scale High
Default
Description
Setting
1
4
1
0xABCD
FA510: 1
FA515: 0
Default
Description
Setting
4
-80
20
17
Modbus
Read Write Unit /Comment
R/W Modbus ID 1...247
R/W 0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 38400
R/W 0 = none
1 = even
2 = odd
R/W 0 = 1 Stop Bit
1 = 2 Stop Bit
R/W 0xABCD = Big Endian
0xCDAB = Middle Endian
R/W 0 = Modbus disabled
1 = Modbus Enabled
Read Write Unit /Comment
R/W 0 = 4-20mA disabled
1 = Temperature [°C]
2 = Temperature [°F]
3 = relative Humidity [%]
4 = DewPoint [°C]
5 = DewPoint [°F]
6 = Absolute Humidity [g/m3]
7 = Absolute Humidity [mg/m3]
8 = Humidity Grade [g/kg]
9 = Vapor Ratio [ppm]
10 = Saturation Vapor Pressur [hPa]
11 = Partial Vapor Pressure [hPa]
12 = Atmospheric DewPoint [°C]
13 = Atmospheric DewPoint [°F]
R/W
R/W
FA 515 V1.07
