Read these operating instructions carefully before installing the FA 515.
!
Failure to observe the instructions contained herein, in particular the
safety instructions, may result in hazards to personnel, equipment and
systems..
•
The product may only be used in accordance with its intended purpose.
•
Installation of the dew point sensor and maintenance work may only be carried
out by trained personnel.
•
Installation and service work must be carried out in a de-energized state.
•
The applicable safety regulations must be observed!
•
All work on the compressed air network must only be carried out in a
depressurized state.
•
Attention: Do not exceed the pressure range > 50 bar for the standard version.
•
Observe the measuring ranges of the sensor!
Overheating will destroy the sensors.
•
Observe the permissible storage and transport temperature as well as the
permissible operating temperature (e.g. protect the measuring instrument from
direct sunlight).
•
Opening the instrument, improper handling or use of force will void all warranty
claims!
•
Important: Before installation, briefly allow compressed air to flow off to remove
condensate and particles, this will prevent soiling of the FA 515.
•
Standing air leads to long measuring times
The FA 515 dew point sensor enables a reliable and long-term stable monitoring of the dew
point in industrial applications. The FA 515 features improved stability.
Advantages:
•
Extremely long-term stable
•
IP 65 housing grants a reliable protection in extreme industrial conditions
•
Very fast response time
•
Installable in the dryer by means of G 1/2" thread, optional UNF 5/8" or NPT ½"
• High accuracy of ± 1...2 °Ctd
•
Calibration on location and testing with CS control and calibration set (PC connection set)
Programming via Software.
With the CS Service Software incl. USB / Modbus Adapter the Modbus settings, the scaling of the
Analogue output and the assignment of the measurement values could be set.
- Analogue output 4...20 mA scalable
- Switching between °Ctd,°Ftd, % RH, °C, °F, g/m³, mg/m³, g/kg, ppm, and so on
- Calibration and adjustment
- Sensor diagnosis
- Read-out of service data
12
NOTES ON SAFETY
DESCRIPTION
FA 515 V1.07
