The FA515 comes standard with a 4...20mA output in 2-wire technique and an RS 485
Modbus output. But it can only be used either the analogue output 4...20 mA or RS 485
Modbus output. Both outputs can not be used at the same time due to the 4...20 mA 2-wire
technology (low power).
Change from 2 wire technolgy to Modbus and back requires the CS Instruments
service software. (Order.No.: 0554 2007)
Before commissioning of the sensor the communication parameters
must be set in order to ensure the communication with the Modbus master.
The adjustment can be done either with the CS Instruments PC service software, DS 400, DS
500 and the hand-held instrument PI 500 done.
Modbus communication default values:
•
Modbus ID : 1
•
Baudrate:
•
Parity:
•
Stoppbit:
Supported are following functioncodes:
•
Function code 03:
•
Function code 16:
Register Mapping measuring values:
Modbus Modbus No.of
Register Address
1001 1000
1003 1002
1005 1004
1007 1006
1009 1008
1011 1010
1013 1012
1015 1014
1017 1016
1019 1018
1021 1020
1023 1022
1025 1024
Remark for DS400 / DS 500 / Handheld devices - Modbus Sensor Datatyp:
„
Data Type R4-32" match with „Data Type Float"
Modbus ID, Baudrate, Parity und Stop bit
19200 bps
even
1
Read Holding Register
Write multiple Register
Data Type
Byte
4 Float Temperature
4 Float Temperature
4 Float Relative Humidity
4 Float Dew Point
4 Float Dew Point
4 Float Absolute Humidity
4 Float Absolute Humidity
4 Float Humidity Grade
4 Float Vapor Ratio (Volume)
4 Float Saturation vapor pressure
4 Float Partial Vapor Pressure
4 Float Atmospheric DewPoint
4 Float Atmospheric DewPoint
(1 -247)
(1200,2400, 4800, 9600, 19200, 38400 bps)
(none, even, odd)
(1,2)
Default
Description
Setting
16
Modbus
Read
Unit /Comment
Write
R [°C]
R [°F]
R [%]
R [°Ctd]
R [°Ftd]
R [g/m³]
R [mg/m³]
R [g/kg]
R [ppm]
R [hPa]
R [hPa]
R [°Ctd]
R [°Ftd]
FA 515 V1.07
