PICTURE Factory
Default
D-EFFECT –

6.7.1 D-ZOOM menu

D-ZOOM menu provides PIP window which displays a zoom area out of full field of view.
PIP window can be ON/OFF and placed at any position by setting in PAN&TILT menu.
D-ZOOM factor is X ~ X64 and the zoom area can be scanned by PAN&TILT.
In PAN&TILT menu, PIP window can be moved when ‚PIP' is displayed at the center of the monitor and a scan area for
zoom can be moved when ‚D-ZOOM' is displayed at center.
‚PIP' to ‚D-ZOOM' change can be done by pressing .
DEFAULT resets all changes in D-ZOOM menu.
NOTE:
When entering to or returning from zoom mode, video mutes about a second to reorganize the video memory
and this is not a failure.
Descriptions
FREEZE: Image freezes and shows the still image when set to ON.
MIRROR: OFF (normal display), MIRROR (Left & right mirrored), V-FLIP (upside
down) and ROTATE (H/V-FLIP)
D-ZOOM: Possible to digitally zoom the image up to x64.
When D-ZOOM is greater than x.0, digital PAN/TILT can be set.
(See 6.7. D-ZOOM)
NEG.IMAGE: If set to ON, Negative image is output and useful to see the negative
film.
