SMA NR3-STP-AC-CON Bedienungsanleitung Seite 11

SMA Solar Technology AG
Quantity
10
1
4 Overview of the Assembly
Figure 1 : Position in the inverter
Position Designation
A Type label of AC assembly (AC-CON) for compatibility check The assemblies
of the spare-part set NR-STP200-ACCON and NR3-STP200-ACCON are not
compatible with the TP-ACCON-XX.XX assembly.
B AC assembly (AC-CON)
C Residual-current monitoring unit (RCMU)
5 Disconnecting the Inverter from Voltage Sources
Prior to performing any work on the inverter, always disconnect it from all voltage sources as
described in this section. Always adhere to the prescribed sequence.
Replacement Manual
Designation
Pan head screw M4x15
Replacement Manual
ACCON-STPTL10-RM-xx-10
4 Overview of the Assembly
A
B
C
11
