SMA Solar Technology AG
5. Tighten all fastening screws except those in the
indicated area (TX20, torque: 3.5 Nm). Use the
new screws supplied for this. The dotted area
remains unequipped after the installation.
6. Connect all connections on the AC-CON. Use the
new ribbon cable supplied.
7. Plug the insulated conductors into the opening of the
AC terminal block and lock them. When doing so,
ensure that the assignment is correct.
8. Recommission the inverter (see Section 8, page 22).
Replacement Manual
7 Installing the AC-CON
ACCON-STPTL10-RM-xx-10 21
