Installation des Geräts II
Installation of the Equipment II
Installation of the separator:
In their standard version, the separator devices RKMR are designed and delivered as rectangular
boxes. They are packed at the factory and delivered on a pallet, depending on their size. The devices
can be transported in an upright position on the pallet with the help of an elevator truck or a forklift
or in hanging position using their suspension lugs. If you desire special installation options such as
suspended mountings or mounting frames, please specify them separately in your inquiry. Please
note that the device is fitted with four-inch sockets at the bottom for the connection of the siphon,
i.e. make sure that the RKMR device is set up in such a manner that the drain line can be connected
to the four-inch sockets. Furthermore, make sure that the position of the separator provides for
easy access to the service side.
Mounting Position:
The position of the device
must be absolutely horizontal.
It must not be installed in a
vertical or inclined position.
Please observe the direction
of the airflow.
ATTENTION:
!
When installing the device, make sure that the drain lines are fitted separately.
This means that the drain hoses must not be connected to each other, i. e. not short-circuited!
Air ducts:
Please refer to our catalogue or the technical data on page 13 for the connecting dimensions of the
separators. Connections that differ from the standard dimensions should be specified separately in
your enquiry. Make sure under all circumstances that the connection of our separators to the on-site
duct system is oil proof, i. e. apply oil- and acid-resistant sealant to the connections.
ATTENTION:
!
The device must never be operated
when the maintenance door is open.
8
