Allgemeine Beschreibung II
General Description II
Exhaust air cleaner with REVEX
Duct-mounting air cleaner, ready for connection, suitable
for installation in a horizontal exhaust air duct. Stable
and torsion-free, welded housing, made of stainless steel,
powder coating in RAL 7035. Maintenance door with
clip fasteners. The bottom part of the device is designed
as an oil- and waterproof collection tray. Patented
spraying technology with cleaning and air-washing function.
A patented drainage receiver provides for the drainage
of the separated liquids. The collection tray is fitted with
four-inch drain sockets. The sockets are suitable for
the connection of a drain with siphon by the customer.
Duct adapters for the connection to the on-site
ductwork are not included in the scope of delivery.
All basic modules can be cleaned
!
and reused – no throwaway filters!
The
flame-arresting capability
was tested by the German TÜV in accordance
with DIN 18869, DIN EN 16828-6 and UL 1046.
Material:
- Housing: stainless steel 1.4016
with a lacquer finish in RAL 7035
Basic module: cells, housing and
frame made of stainless steel 1.4016,
profiles made of aluminium
Special edition:
- Frame made of stainless steel 1.4301 /
profiles made of aluminium
- Frame made of stainless steel 1.4301 /
profiles made of stainless steel 1.4301
spraying technology.
®
of the device
Fig.: REVEX
spraying system
®
1 &6
! , +
* ?@ ?
A
Fig.: X-CYCLONE
®
separating cells, type RMZ
? @ B ?
8 C ? @ B ?
3
) D E !&
4
