CONTROL UNIT P.TILT RTS M+L
Protection against ice / snow
In the event of ice / snow, the pergola positions itself at the
position defined during configuration.
The temperature sensor is integrated into the central unit. The triggering threshold will depend on the
installation conditions.
(1)When the rain sensor is active, refer to the control point instructions
TIPS AND ADVICE ON OPERATION
3. 5. 2. Questions about the CONTROL UNIT P.TILT RTS M+L?
The motorised product does not
work.
If the motorised product still does not work, contact a drive and home automation professional.
4. TECHNICAL DATA
Radio frequency
Protection rating
Electrical insulation
Operating temperature
Dimensions (l x w x h)
Maximum number of control points
associated sensors
Power supply
Maximum power
Motor current according to switch 3
Light current
Type action
Pollution degree
Impulse voltage
SOMFY ACTIVITES SA hereby declares that the radio equipment covered by these instructions
is in compliance with the requirements of Radio Directive 2014/53/UE and the other
essential requirements of the applicable European directives.
The full text of the EU conformity declaration can be found at www.somfy.com/ce.
Philippe Geoffroy, Head of Certification, on behalf of the Activity Director, Cluses, 03/2020.
©
Copyright 2019 - 2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved.
The drive is hot.
433.42 Mhz
IP 65
Class 3 (SELV)
- 20°C to + 60°C
99 x 205 x 57 mm
Maximum of 3 control points
and
Maximum of 9 sensors
12 or 24 Vdc SELV Safety Isolating Transformer
228 W
3 A or 5 A
4 A
1
2
500 V
Wait for the drive to cool down.
