16. Power-Schalter – Über diesen Schalter schalten Sie Fast Track Pro ein. Im eingeschalteten Zustand leuchtet die Power-LED
(13) auf der Vorderseite des Geräts. Vor dem Einschalten müssen Sie Fast Track Pro an den USB-Anschluss Ihres Computers
anstecken oder über ein externes Netzteil an das Stromversorgungsnetz anschließen.
17. Kensington Lock – Dieser Anschluss ist für Kensington
schützen.
Lock Clearance Specifications and Electrical Considerations
The Notebook MicroSaver has an interference volume inside
the computer equipment it secures. There should not be any
electrical components adjacent to the slot, and the MicroSaver
product should never be in contact with any electrical
components.
3.00
Kensington Security Slot
All measurements are in millimeters
Slot Outside Clearance
All measurements are in millimeters
Security Slot Specifications
+.26
7.00
–.00
+.26
–.00
4 * R 1.00 max
R18.50
Cable ring can
rotate 360° with
respect to slot
R30.00
Lock at base
Kensington Technology Group
2000 Alameda de las Pulgas
San Mateo, CA 94403
® -Sicherungssysteme vorgesehen, um Ihr Gerät vor Diebstahl zu
Notes:
1. Interpret dimensions and tolerances per ASME Y14.5M-1994.
2. All indicated dimensions are in millimeters. Indicated
volume to be left free and clear of obstructions. Cable ring
can rotate 360 degrees with respect to hole.
Cable
Rotating cable
ring
22.60
26.60
Slot Clearance—Side view
All measurements are in millimeters
R 3.50
Slot Inside Clearance
All measurements are in millimeters
© 2002 Kensington Technology Group, a division of ACCO Brands, Inc. All rights
reserved. Kensington is a registered trademark of ACCO World Corporation.
4
Wall thickness
range including
metal backing
2.50 to 4.00
Metal backing
recommended
> 0.8 stainless
steel
7.70
Min. clearance
