Checking the vertical line: Position the device about 5 m from a wall. Fix a
plumb bob with a line of 2.5 m length on the wall, making sure that the bob
can swing freely. Switch on the device and align the vertical laser to the plumb
line. The precision is within the specified tolerance if the deviation between the
laser line and the plumb line is not greater than ± 1.5 mm.
Checking the horizontal line:
Position the device about 5 m from a wall and
switch on the cross laser. Mark point B on the wall.
Turn the laser cross approx. 2.5 m to the right and
mark point C. Check whether the horizontal line
from point C is level with point B to within ± 2 mm. Repeat the process by
turning the laser to the left.
!
Regularly check the calibration before use, after transport and after
extended periods of storage.

Technical data

Self-levelling range
Precision
Laser wavelength line lasers
Laser class / Laser output rating line lasers
Power supply
Battery life
Weight (incl. batteries)
Dimensions (W x H x D)
Operating temperature
Storage temperature
Subject to technical alterations
CompactPalm-Laser PowerBright Plus
2,5 m
B
1,5°
± 2 mm / 10 m
635 nm
2M / < 5 mW
3 x 1,5V AA
ca. 14 h
0,6 kg
110 x 65 x 106 mm
0°C ... + 50°C
-10°C ... + 70°C
01/2010
C
