Horizontal and vertical levelling
Switch on the device. Turn the ON / OFF switch (7) upward and release the
transport lock. Now the laser device will be automatically aligned by the
pendulum system and the status indicator will illuminate constantly. Now the
device can be levelled horizontally and vertically.
The lasers can be switched on and off individually with the H and V buttons.
If the device is too far off the horizontal (more than 1,5°), the lasers
!
will blink. Align the device using the adjustable feet (4) or place on a
more level surface.
Positioning laser lines
The top section of the laser device can be turned on its plinth to align the
lasers.
Hand receiver mode
Optional: Working with the laser receiver RX
Use an RX laser receiver (optional) to carry out levelling at great distances or
when the laser lines are no longer visible.
To work with a laser receiver, switch the line laser into hand receiver mode
with the Hand receiver mode button (12). The laser lines will now pulsate
with high frequency, making the laser lines darker. The laser receiver can
detect these pulsating laser lines.
!
Observe the laser receiver's operating instructions for line lasers.
