Electrode diameter
0 to 4.0 mm (0.158 in.),
Factory setting: 2,4 mm (0.095 in.)
Available parameters where 4-step mode (3) has been selected:
Starting current Is
0 to 100 % of main current I
Factory setting: 35%
IMPORTANT! The starting current IS is saved separately for the "TIG-
AC welding" and "TIG DC- welding" operating modes.
Upslope t
0.0 to 9.9 s, factory setting: 0.1 s
IMPORTANT! The upslope tup is saved separately for the 2-step and 4-
step operating modes.
Main current I
- MagicWave 1700: 3 to 170 A
- MagicWave 2200: 3 to 220 A
IMPORTANT! On welding torches with Up/Down functionality, the enti-
re setting range is available for selection while the machine is idling. Du-
ring welding, the main current can be corrected by +/-20 A.
Reduced current I
0 to 100 % of main current I
Factory setting: 50%
Downslope t
0.0 to 9.9 s, factory setting: 1 s
WICHTIG! The downslope t
4-step operating modes.
Final current I
0 to 100 % of main current
Factory setting: 30 %
Balance (only with TIG-AC)
-5 / +5, factory setting: 0
-5 highest fusing power, lowest cleaning action
+5 highest cleaning action, lowest fusing power
Electrode diameter
0 to 4.0 mm, (0.158 in.)
Factory setting: 2.4 mm (0.095 in.)
Available parameters where "Job mode" (4) has been selected:
In "Job mode", the parameters that apply to the operating mode that
has been stored in the selected job are made available. In addition, the
following parameter is also available:
Job number
for selecting the desired job
Available parameters where the "Rod electrode (MMA) welding" mode
(5) has been selected:
1
up
1
2
1
down
is saved separately for the 2-step and
down
