Connecting up Insert the plug at the end of the remote-control cable into the LocalNet connec-
the remote con- tion socket (A).
trol unit
Front view MW/TT 1700/2200
Rear view TS/TPS 3200/4000/5000
Keylock switch
(A)
(A)
(C)
Front view TPS 2700
(A)
Front view TP 4000/5000
IMPORTANT! When the keylock switch
is in the horizontal position (B), all the
buttons on the control panel are disab-
led:
- The "key" symbol (C) is lit up on
the control panel
- If you still press any of the but-
tons, the disabled message "Clo|
SEd" will briefly appear on the dis-
plays. The only parameter that it is
possible to alter (with the adjus-
ting dial) is the one that was alrea-
(B)
dy selected at the time the keylock
was activated.
(A)
