(7)
(8) +
(9)
16
If "Job mode" (4) has been selected, the display shows the process that
was saved for the current job.
If "Rod electrode (MMA) welding mode" (5) has been selected:
Process:
Rod electrode DC+ welding
Rod electrode DC- welding
Rod electrode AC welding
Adjusting dial
for altering parameters. If the indicator is lit up on the adjusting dial,
then the selected parameter can be altered.
Parameter selection buttons
for selecting the parameters It is also possible to change parameters by
means of the parameter selection buttons (8) and (9) while the welding
operation is in progress.
Available parameters where 2-step mode (2) has been selected:
Starting current Is
0 to 100 % of main current I
Factory setting:35%
IMPORTANT! The starting current I
AC welding" and "TIG DC- welding" operating modes
Up-Slope t
0.0 to 9.9 s, factory setting: 0.1 s
IMPORTANT! The upslope tup is saved separately for the 2-step and 4-
step operating modes.
Main current I
- MagicWave 1700: 3 to 170 A
- MagicWave 2200: 3 to 220 A
IMPORTANT! On welding torches with Up/Down functionality, the enti-
re setting range is available for selection while the machine is idling. Du-
ring welding, the main current can be corrected by +/-20 A.
Downslope t
0.0 to 9.9 s, factory setting: 1 s
IMPORTANT! The downslope t
and 4-step operating modes.
Final current I
0 to 100 % of main current
Factory setting: 30 %
Balance (only with TIG-AC)
-5 / +5, factory setting: 0
-5 highest fusing power,
lowest cleaning action
+5 highest cleaning action,
lowest fusing power
1
is saved separately for the "TIG-
S
up
1
down
is saved separately for the 2-step
down
E
