Lenz Digital Plus SILVER+PluX22 Information Seite 39

Configuration of the GPIO-Connection (Pin 1)
65
This pin can be configurated as an input or output pin.
Value 0...28 => Connection is an OUTput and responds to
functions 0 ... 28.
Value 100 ... 128 => Connection is an Input. When activated,
(pulled to Ground) function 0...28 is switched on.
The decoder behaves, as if he had received the function through
a DCC-Packet.
Function mapping for Output I
66 0-28
Enter the number of the desired function.
0-255 Values for characteristic speed line
67..
94
112 0-255 Duration of motor timeout when track signal has stopped.
t = CV112 * 0.016sec, default approx. 0.25 sec
113 0-255 Minimum PWM value, control for motor types 4 or 5
114 0-255 Change duty cycle for motor type 4 or 5
0-255
116 Sets brightness at function output C, 255=max
0-255 Sets brightness at function output D, 255=max
117
0-255 Sets brightness at function output E, 255=max
118
126 0-255 CV (indicator) for S.U.S.I., offset 800
127 0-255 CV (transport device) for S.U.S.I.
128 Service number (Please read out the number)
39
10
E
9
16
40
10
255
255
255
102
0
-
