For detailed instructions on how to program using the above-mentioned devices, please refer to the
operating manuals which accompany those devices.
The decoder is programmed ex-works for operation with address 3 and 28 running notches. The
decoder can be used with these basic configurations immediately after purchase.
5.1 Resetting the decoder
If you wish to reset all the decoder CVs to the ex-works setting, enter value 8 or 33 in CV8. The CVs
of a connected S.U.S.I. module are not reset!
6 Table of supported CVs
Bit 2 (1): The number in front of the brackets represents the bit number for the counting method
starting from 1; the number in brackets shows the bit number starting from 0.
Value /
CV Meaning
Bit
1 1-127 Basic locomotive address. This number is used to call up
locomotives in the Digital plus by Lenz
range 1-99 is recommended for operation with
Digital plus by Lenz
When writing this CV, CV19 (multiple traction address) is
automatically deleted in the decoder and Bit 6 (use of extended
address) is deleted in CV29.
2 0-255 Minimum starting voltage
3 0-255 Starting delay
4 0-255 Braking delay
0-255
5 Maximum speed
®
system. The use of
®
devices.
33
E
Ex-works
setting
3
1
6
5
254
