Network configuration
To connect the device to a power supply unit, use the provided 2-pole
terminal and lay the wires as stated on the front label. The voltage
assignment is left V+ and right V-.
Turn the power on when all cables are connected to the SYMPL dmx Node.
The device starts booting. The device has finished booting and is in
operation when the LED Status is flashing.
The SYMPL dmx Node is not suited for powering over a DC
!
power supply network. Use a separate certified SELV Class 2
power supply unit in the control cabinet for supplying 24 V
DC to the SYMPL dmx Node.
5 Network configuration
The configuration of the e:cue SYMPL dmx Node is completely done via
e:cue SYMPHOLIGHT. See the SYMPHOLIGHT System Manual for details
on configuration, available at www.ecue.com.
The network properties of the SYMPL dmx Node are preconfigured. The
successful installation of the power supply is required for changing the
network configuration. You can either adjust the network settings with
SYMPHOLIGHT or using the web interface of the SYMPL dmx Node. Via
the web interface extended DMX/RDM settings are configurable.
5.1 Default network properties
The SYMPL dmx Node has as factory setting the default IP address
192.168.123.1.
DHCP is enabled by default.
Login credentials for the web interface of the SYMPL dmx Node:
The default password is: ecue
To change the network configuration use either SYMPHOLIGHT or the web
interface of the SYMPL dmx Node:
