Battery Installation and Detachment
Installation
1. Aim the battery into the battery compartment of the flash.
2. Insert the battery into the compartment with a click sound. The battery is
successfully installed when the battery release button slides to the right
automatically.
If your heard a "clicks" but the battery release button only slid to the middle and
stopped, the battery is not installed correctly. Please push the battery again until
a" click" occurs and the battery release button slide to the right automatically.
Detachment
Push the battery release button to the left until the battery pops out.
Note: Please catch the battery with your hands when you are detaching, in case of
affecting the battery's service life due to falling.

Battery Level Indication

Make sure the battery pack is securely loaded in the flash. Check the battery level
indication on the OLED panel to see the remaining battery level.
Battery Level
Indication on the
OLED panel
3 grids
2 grids
1 grid
Blank grid
Blinking
Meaning
Full battery
Medium battery
Low battery
Lower battery, please recharge it
The battery level is going to be used out immediately. And
the flash will auto power off in 1 minute.
Note: Please recharge the battery as soon s possible (within
10 days). Then, the battery can be used or be placed for
long period.
