GridScan/Mini-SB2/-ST2
Tx
Rx
5.3

Alignment

≤ 5˚
Tx
< 3 m
Reflective surface
Tx
6.

Application overview

Connection cable
Receiver edge
Door
controller
Figure 6:
GridScan/Mini-SB2/-ST2 application (overview)
6
Tx
Rx
≤ 5˚
Rx
Rx
Synchronization cable
 Make sure to place the connection plugs for both the
emitter and receiver at the same end.
The optical axis of the emitter (Tx) and the receiver edge
(Rx) need to be aligned towards each other to ensure the
light curtain functions reliably.
Reflective surfaces near to or parallel to the safeguarded
area can cause reflections and interfere with the
GridScan/Mini-SB2/-ST2's functions. Keep a reasonable
distance between the sensor edges and any reflective
surface.
Door operator
Emitter edge
Figure 7:
Figure 8:
English
GridScan/Mini-SB2 with
door blanking
GridScan/Mini-ST2 with
static mounting
