TECEplanus – urinal electronic
Programming the TECE electronic
About five seconds after it has been connected to the
power supply, the TECE electronic can be programmed in
the first 30 minutes. Every adjustable function is set to a
default position.
Position Function
1 Break function "off"
2 Break function "on"
3 Flush time 2 s
4 Flush time 2,5 s
5 Flush time 3 s
6 Flush time 3,5 s
7 Flush time 4 s
8 Flush time 5 s
9 Flush time 6 s
10 Flush time 8 s
11 Flush time 10 s
12 Preflush off
13 Preflush 0,5 s
14 Preflush 1 s
15 Preflush 2 s
16 Hygienic flush off
17 Hygienic flush 24 h
18 Hygienic flush 255 h
19 Sensor sensitivity "low"
... ...
23 Distance "standard"
24 Distance "short"
25 Distance "long"
... ...
28 Default setting
29 Urinal incl. cover "off"
30 Urinal incl. cover "on"
= Default setting
To program the TECE electronic:
Hold the programming key in front of the
sensor window (see illustration).
Programming mode will start with a rapid
sequence of short beeps.
A sequence of even individual beeps will
sound during the starting phase.
Count these until the desired function
is reached.
Now remove the programming key.
A longer acknowledgement beep will sound.
Example: Setting the flush time to three seconds
. . . .
Start 1 2
Hold the programming Count the individual beeps
key in front of the until the desired position is
sensor reached
All manuals and user guides at all-guides.com
3 4 5 OK
Remove programming
key
Break function
When the break function is switched on, the flush volume
is automatically reduced by shortening the flush time to
one second if the urinal is used in rapid succession
(i.e. at intervals of less than two minutes). A flush with the
normal flush volume is triggered 45 minutes after the last
short flush.
< 2 min
< 2 min
> _ 2 min
< 2 min
> 45 min
* Can be set to between 2 and 10 seconds
Cleaning function
When you activate the cleaning function, the flush function
will be interrupted for ten minutes. At the end of this time,
a cleaning flush will automatically be triggered and standard
operation will be restored.
Activating the cleaning function: Hold the programming
key briefly in front of the sensor window.
An acknowledgement beep will sound.
Deactivating the cleaning function:
Hold the programming key briefly in front of the sensor
window. Three acknowledgement beeps will sound in
succession and the electronic will be returned to
standard operation.
The cleaning function can be activated only in standard
operating mode, not during the programming phase.
english
3 s standard
flush time*
1 s shortened
flush time
1 s shortened
flush time
3 s standard
flush time*
1 s shortened
flush time
3 s standard
flush time*
