DMX-protocol

Control channel 1 - Gobowheel
Channel DMX-value
000-007
1
008
009
010
011
012
013
014
015
016-255
Control channel 2 - Effectwheel
Channel DMX-value
000 - 007
2
008-127
128-135
136-255
Control channel 3 - Shutter, Strobe
Channel DMX-value
000-007
008-015
016-131
132-139
3
140-180
181-189
190-231
232-239
240-247
248-255
Control channel 4 – Dimmer intensity
Channel DMX-value
4 000-255
Function
Home
Index-Position 1
Index-Position 2
Index-Position 3
Index-Position 4
Index-Position 5
Index-Position 6
Index-Position 7
Index-Position 8
Rainboweffect, increasing speed
Function
Stop
Forward rotation with increasing speed
Stop
Backward rotation with increasing speed
Function
Blackout
Shutter open
Strobe-Effect with increasing speed
Shutter open
Pulse opening with decreasing speed
Shutter open
Pulse closing with decreasing speed
Reset after 3-5 seconds
Random strobe-effect
Shutter open
Function
Gradual adjustment of the dimmer intensity, 0 to 100 %
22/24 00090715.DOC, Version 1.2
