If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
WEEE Directive
When to be definitively put out of operation, take the unit(s) to a local recycling plant for a disposal which is
not harmful to the environment. Do not dispose of as municipal waste. Contact your retailer or local
authorities for more information.
Features
Extraordinary decorative illumination: LED kaleidoscope effect
Equipped with one white COB LED
•
DMX-controlled operation or Stand Alone operation with Master/Slave-function (up to 4 slaves)
•
Sound-controlled via built-in microphone
•
•
Microphone-sensitivity adjustable via rotary-control
•
Rainbow effect with adjustable speed
With gobo-shake function
•
Strobe effect with adjustable speed
•
Random strobe effect
•
Manual focus
•
Dimmer
•
Fan-cooled
•
Comfortable addressing and setting via control panel with 4-digit LED screen and three operating
•
buttons
¼" jack-socket for remote control
•
Blackout, gobos, colors and Auto/Manual Mode applicable in Stand Alone mode via optional
•
EUROLITE RC-1 remote control
DMX-control via any standard DMX-controller
•
Ready for connection via included IEC power cord with safety power plug
•
INSTALLATION
Overhead rigging
Please consider the EN 60598-2-17and the respective national standards during the installation!
The installation must only be carried out by an authorized dealer!
The installation of the device has to be built and constructed in a way that it can hold 10 times the weight for
1 hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall down
if the main attachment fails.
When rigging, derigging or servicing the device staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert before taking into operation for the first time and after changes before taking into operation another
time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
DANGER TO LIFE!
17/24
00090715.DOC, Version 1.2
