Remote Control socket
If you wish to lock the light output - via an optional EUROLITE RC-1 remote control, connect your RC-1
remote control to the remote control socket.
The remote control RC-1 can be used for switching the gobos, colors and the Auto/Manual mode. In Auto
Mode, the gobos and colors are switched sound-controlled. In Manual Mode, the gobos and colors are
switched via remote control.
Mode
Red control-
Sound Mode
Auto Mode
Blackout
DMX-controlled operation
You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.
Addressing
The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED GKF-60 DMX / LED GKF-150 DMX Kaleidoscope Effect will respond to the controller.
Please, be sure that you don't have any overlapping channels in order to control each LED GKF-60 DMX /
LED GKF-150 DMX Kaleidoscope Effect correctly and independently from any other fixture on the DMX data
link.
If two, three or more LED GKF-60 DMX / LED GKF-150 DMX Kaleidoscope Effect devices are addressed
similarly, they will work similarly.
For address setting, press the Mode-button until the display shows „A.001" and set the desired address via
the Up/Down-buttons.
Controlling:
After having addressed all LED GKF-60 DMX / LED GKF-150 DMX Kaleidoscope Effect devices, you may
now start operating these via your lighting controller.
Note:
After switching on, the LED GKF-60 DMX / LED GKF-150 DMX Kaleidoscope Effect will automatically detect
whether DMX 512 data is received or not. If the data is received, the display will show "A.001" with the
actually set address. If there is no data received at the DMX-input, the display will show "A001".
This situation can occur if:
- the 3 Pin XLR plug (cable with DMX signal from controller) is not connected with the input of the LED GKF-
60 DMX / LED GKF-150 DMX Kaleidoscope Effect.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Green control-
LED
LED
ON
OFF
OFF
ON
OFF
OFF
Button 1
Button 2
Sound
Auto
available
--
available
--
--
21/24
Button 3
Blackout
--
--
available
00090715.DOC, Version 1.2
