Stand-alone mode
Preset colors
In the STATIC mode the device will constantly emit one of 28 preset colors.
1
Press the MENU button so many times until STATIC is indicated in the display. Confirm with the ENTER
button.
2
Use the buttons UP and DOWN to adjust the desired color. Confirm with the ENTER button.
Automatic mode
In automatic mode, 9 show programs are available that run at an adjustable speed.
1
Press the MENU button so many times until AUTO is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (01 – 09). Confirm with the
ENTER button.
2
Press the MENU button so many times until SPEED is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from 01 (slow) to 09
(fast). Confirm with the ENTER button.
Color mix
In COLOR mode each of the 7 colors can be individually adjusted in intensity. The device will then constantly
emit the chosen color setting.
1
Press the MENU so many times until COLOR is indicated in the display. Confirm with the ENTER button.
2
Now the display indicates the letter R for the color red and the corresponding brightness value. Use the
buttons UP and DOWN to adjust the desired brightness.
3
Confirm with the ENTER button. Now the color green can be set; then blue, cold white, warm white,
amber and UV until the desired color intensity is achieved.
Color temperature
In the TEMPERAT mode the device will constantly emit white light. The color temperature of the light beam
is adjustable.
1
Press the MENU button so many times until TEMPERAT is indicated in the display. Confirm with the
ENTER button.
2
Use the buttons UP and DOWN to adjust the desired color temperature. Confirm with the ENTER button.
Total brightness
The menu point DIMMING allows adjusting the total brightness for all stand-alone operating modes: STATIC,
AUTO, COLOR and TEMPERAT.
1
Press the MENU button so many times until DIMMING is indicated in the display. Confirm with the
ENTER button.
2
Use the buttons UP and DOWN to adjust the desired brightness (01 = dark, 99 = bright). Confirm with
the ENTER button.
Fading program
In FADING mode the speed for fading can be set.
1
Press the MENU button so many times until FADING is indicated in the display. Confirm with the ENTER
button.
2
Use the buttons UP and DOWN to adjust the desired speed (00-99). Confirm with the ENTER button.
Strobe effect
In FLASH mode the speed for strobe effect can be set.
1
Press the MENU button so many times until FLASH is indicated in the display Confirm with the ENTER
button.
2
Use the buttons UP and DOWN to adjust the desired speed (00-99). Confirm with the ENTER button.
DMX lost
In DMX lost mode the program offers different options when no DMX signal is received.
1
Press the MENU button repeatedly until the display shows the DMX lost menu. Press ENTER to
confirm.
2
Select the desired program with the UP and DOWN buttons (see menu structure). Confirm with ENTER.
25/32
00129734, Version 1.0
