EN
1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.
1.2 OVERVIEW
Figure 1 - 20.
Battery release button
1
Rear handle
2
Trigger
3
Lock-out button
4
Speed switch
5
Auxiliary handle
6
Upper shaft
7
Coupler
8
Lower shaft
9
Trimmer head
10
Cut-off blade
11
Guard
12
Knob
13
Release button
14
Positioning hole
15
Bolt
16
Lower clamp
17
Knob
18
Tab
19
Spool cover
20
Spool housing
21
Spool
22
Line exist hole
23
Bump knob
24
Angle transmission hole
25
Metal rod
26
Blade
27
Inner cup
28
Plate
29
Outer cup
30
Nut
31
Direction of roatation
A
Best cutting area
B
Dangerous cutting area
C
1.3 PACKING LIST
1 String trimmer bare
tool
English
2 Brush cutter blade
3 Auxiliary handle
4 Guard
5 Wrench
2 GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
3 INSTALLATION
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine before
use.
WARNING
• If parts of the machine are damaged, do not use the
machine.
• If you do not have all the parts, do not operate the
machine.
• If parts are damaged or missing, contact the service
center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with
local regulations.
WARNING
For your personal safety, do not insert battery before the
tool is assembled completely.
3.2 ATTACH THE GUARD
Figure 2.
WARNING
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a Phillips
head screwdriver (not included).
2. Put the guard onto the trimmer head.
6
6 Metal rod
7 Shoulder harness
8 Operator manual
