EN
1

DESCRIPTION

1.1

PURPOSE

This machine is used to cut grass, light weeds, and other
similar vegetation at or around ground level. The cutting
plane must be approximately parallel to the ground surface.
You cannot use the machine to cut or chop hedges, shrubs,
bushes, flowers and compost.
1.2

OVERVIEW

Figure 1 - 18.
Trigger
1
Rear handle
2
Lock-out button
3
Auxiliary handle
4
Upper shaft
5
Coupler
6
Lower shaft
7
Edger button
8
Guard
9
Cut-off blade
10
Edge guide
11
Trimmer head
12
Edger wheel
13
Pivoting button
14
Screw
15
Battery release button
16
Spool retainer button
17
Tab
18
Spool cover
19
Spool
20
Spool housing
21
Hole
22
Direction of roatation
A
Best cutting area
B
Dangerous cutting area
C
2

SAFETY

Make sure that you do/obey all safety instructions.
Refer to Safety Manual.
3

INSTALLATION

Remove the battery pack from the machine before
installation.
WARNING
WARNING
English
Do not use accessories that are not recommended for this
machine.
3.1

UNPACK THE MACHINE

Make sure that you correctly assemble the machine before
use.
If parts of the machine are damaged, do not use the
machine.
If you do not have all the parts, do not operate the
machine.
If the parts are damaged or missing, contact the service
center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with local
regulations.
3.2

ATTACH THE GUARD

Figure 2.
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a Phillips
head screwdriver (not included).
2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw holes
on the trimmer head.
4. Tighten the screws.
3.3

ASSEMBLE THE SHAFT

Figure 3.
1. Insert the lower shaft into the coupler on the upper shaft.
Make sure the upper and lower part of shafts are securely
tightened before installing the battery pack again.
2. Tighten the coupler.
3.4

INSTALL THE BATTERY PACK

Figure 4.
4
WARNING
WARNING
WARNING
WARNING
NOTE
