General

Safety

Incorrect operation and faulty work can cause serious personal injury and mate-
rial damage.
All work and functions described in this document must be performed only by
trained specialist personnel who have read and understood the following docu-
ments in full:
▶
▶
▶
Connections and
indicators on RJ
45 module
(11)
(12)
(13)
(14)
Network Status LED
Status
Off
Lights up green
Flashes green (once)
Flashes green (per-
manently)
28
WARNING!
this document
the Operating Instructions of the robot interface "RI FB Inside/i"
all documents relating to system components, especially the safety rules
(9) (10)
(1) (3) (5) (7)
(2) (4) (6) (8)
(13) (14)
RJ-45 Ethernet connection 2
RJ-45 Ethernet connection 1
Connection/activity LED, connection 1
NS LED (network status)
Meaning
Offline; no power supply or no connection with IO Con-
troller
Online (RUN); connection with IO Controller establis-
hed,
IO Controller in operation
Online (STOP); connection with IO Controller establis-
hed, IO Controller not in operation, IO data defective,
IRT synchronization not ready
In use by engineering tools in order to identify network
nodes
(1) TX+
(11) (12)
(2) TX-
(3) RX+
(6) RX-
(4) Not normally used; to ensure
signal completeness, these
(5)
pins must be interconnected
(7) and, after passing through a
filter circuit, must terminate
(8)
at the ground conductor (PE).
(9) Connection/activity LED,
connection 2
(10) MS LED (module status)
