Technical Data - CCV Pad Next Erste Schritte

Technical
data
CPU/ Memory
32-bit Cortex-A9 CPU 1000 MHz/ 512 MB Flash and 512
MB SDRAM
Keypad
10 numeric keys, 3 function keys, back-lightning, reset
button
Display
4 Inch 800 x 480 pixels capacitive touch screen,
integrated signature pad
Communication/ Peripheral Ports
Ethernet + WiFi, RS232, USB, Bluetooth (with Beacon), 3
SAM slots, front camera (for QR-Code, barcode...)
Card Reader
• Track 1/ 2/ 3, bi-directional
• Smart Card Reader EMV L1 & L2
• Contactless Reader MasterCard contactless & Visa
contacless, ISO/ IEC 14443 Type A/ B, MIFARE,
FeliCa, American Express contactless, girogo (TA 7.1),
girocard contactless
Declaration of
Conformity
CE Declaration of Conformity
Hiermit erklärt die CCV GmbH, dass der Funkanlagentyp CCV Pad Next und
dessen Netzteil der Richtlinie 2014/53/EU entspricht.
Die vollständigen Texte der EU-Konformitätserklärungen sind unter der folgenden Internetadresse verfügbar:
https://www.ccv.eu/de/partner-integratoren-netzbetreiber/integrierte-bezahlloesung/ccv-pad-next/
CE Declaration of Conformity
Hereby declares CCV Germany GmbH the accordance of the radio equipment CCV Pad Next and
its power supply to the directive 2014/53/EU.
The complete texts of the EU declarations of conformity are available on following internet address:
https://www.ccv.eu/de/partner-integratoren-netzbetreiber/integrierte-bezahlloesung/ccv-pad-next/
Power Supply
Input: 100-240 VAC, 50 /60 Hz, Output: 5V / 1A
Physical (L x W x H)
199 x 112 mm x 53,1, Weight 400g
Environmental
Operation temperature:
temperature: -20°C to 70°C, 5%...95% relative humidity,
non-condensing
Certifications
DK TA7.2, DC POS 3.0, EMV, RoHS, CE, PCI PTS 5.x, P2PE
(optional)
Audio
Speaker
0°C to 50°C, storage
23
