Start-up

5.1

Installation and pairing

Please read this entire section before starting the adding proce-
dure!
First set up your Homematic IP Access Point via the Homematic IP
app to enable operation of other Homematic IP devices within your
system. For further information, please refer to the operating manual
of the Access Point.
To integrate the pluggable dimmer into your system and enable it to
communicate with other Homematic IP devices, you must adding the
device to your Homematic IP Access Point first.
To adding the pluggable dimmer, please proceed as follows:
• Open the Homematic IP app on your smartphone.
Select the menu item "Adding device".
•
• Plug in the pluggable dimmer into the desired socket (see figure
2).
• Pairing mode remains activated for 3 minutes.
You can manually start the pairing mode for another 3 minutes by
pressing the system button (A) shortly (see figure 3). The pluggable
dimmer will be switched on or off (depending on the previous state).
• Your device will automatically appear in the Homematic IP app.
• To confirm, please enter the last four digits of the device number
(SGTIN) in your app or scan the QR code. Therefore, please see
the sticker supplied or attached to the device.
• Please wait until pairing is completed.
• If adding was successful, the LED lights up green. The device is
now ready for use.
• If the LED lights up red, please try again.
• Please select, in which application (e.g. light and/or security) you
would like to use the device.
• In the app, give the device a name and allocate it to a room.
