Function and device overview

The device may only be operated within residential buildings.
3 Function and device overview
With the Homematic IP Pluggable Dimmer connected loads (e.g. lights)
can comfortably be switched on or off and dimmed via a Homematic IP
Remote Control or the Homematic IP app.
The pluggable dimmer is connected quickly and without any tools.
Simply plug in the device to a socket and it is immediately ready for use.
Thanks to the compact design, the pluggable dimmer does not block the
surrounding sockets.
Once installed, the device offers dimming and switching of e.g. incandes-
cent lamps, HV and LV halogen lamps (with electronic transformer) and
dimmable energy-saving lamps as well as many dimmable LEDs.
Device overview (see figure 1):
(A) System button (adding, switching connected loads on and off, LED)
4

General system information

This device is part of the Homematic IP smart home system and works
with the Homematic IP radio protocol. All devices of the system can
be configured comfortably and individually with the Homematic IP
smartphone app. The available functions provided by the system in
combination with other components are described in the Homematic IP
User Guide. All current technical documents and updates are provided at
www.eQ-3.de.
