English
If the condensation hood is used at the
n
same time as other units, ensure there
is sufficient ventilation at the setup
location.
If other units with open exhaust out-
n
lets are operated at the setup location,
make sure there is sufficient ventila-
tion to prevent backflow of exhaust
fumes.

2.3 Intended use

The condensation hood is exclusively in-
tended for the ventilation and discharge of
exhaust air in commercial and industrial
kitchens. All other uses are not authorised
for the intended purpose, and are not per-
mitted.
The use of the condensation hood is back-
wards compatible with an adapter kit. Ask
your Service Partner for the appropriate
adapter kit.
3

Product description

3.1 Technical data

General
Voltage 1 NAC 230V / 2 AC 200V
Connected
load
Exhaust
volumes
Noise emis-
sion (in all
operating
modes)
Weight approx. 25 kg [55.1 lbs]
16 / 136
6-2/3
170 W
280 - 560 m³/std.
< 60 dBA
80.51.574_iCombiPro-iCombiClassic_UV-XS_IM_EU-west
Adapter kit
Adapter kit
Units in the year of
manufacture:
09/2016 – 01/2023
Units in the year of
manufacture:
Year of manufacture:
from 02/2023
Dimensions
Width mm [inch]
Height mm [inch]
Depth mm [inch]
Rear overhang depth
mm [inches]
Front overhang depth
mm [inches]
Minimum clearance
to ceiling mm [inches]

3.2 Scope of delivery

Scope of delivery [
1
2
3
4
Scope of delivery retrofit kit [
1
2
3
4
3 | Product description
Article number
60.73.945
60.78.383
6-2/3
657 [25 7/8]
240 [9 1/2]
580 [22 7/8]
10 [3/8]
75 [3]
450 [18]
Photo 01]
UltraVent XS
Stem
Cover plate for units
with right-hand stop
Cover plate for units
with left-hand stop
Figure 02]
Control cable with PG
screw connection
Pipe angle
Hose clamps
Connecting hose
