PROCESS AND DIALOGUE MODULE
y
CR1071
Process and dialogue
module
PDM 360 smart
128 x 64 pixels
monochrome display
12 freely programmable
backlit function keys
4 inputs / 4 outputs
10...32 V DC
Technical data
Display
Display
Background illumination
Contrast
Sets of characters
Mechanical data
Mounting variants
Dimensions (W x H x D)
Cutout for panel mounting (W x H)
Housing material
Protective film
Keys
Encoder
Protection
Operating temperature
Storage temperature
Weight
Electrical data
Operating voltage
Current consumption
Short-circuit / reverse polarity protection
Processor
Program and data memory
Data memory
Data memory (remanent)
Data memory (retain)
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen
30
PAGE
PDM 360
SMART
F1
F4
esc
COG, monochrome, transflective, with graphics capabilities,
128 x 64 pixels, 59 x 30.5 mm (2.5")
adjustable in 26 steps via the configuration menu
support from the front via lip around the cover,
fixing with clips when mounted into a panel
or mounting brackets when mounted into a control cabinet
(mounting accessories not included)
die-cast zinc, powder coated (RAL 9006)
12 short-stroke keys, with tactile feedback
backlit (brightness 0...100% adjustable)
freely programmable (softkey function)
We reserve the right to make technical alterations without prior notice.
109
F2
F3
F5
F6
ok
Intelligent compact display
for use in mobile machines
LED
can be uploaded individually
• panel mounting
• surface mounting
®
via RAM
mount system
109 x 165 x 53.4 mm
103 ± 0.5 x 154 ± 0.5 mm
polyester with embossed keys
–
IP 67
-20...+70° C
-30...+80° C
1.24 kg
10...32 V DC
240 mA (at 24 V DC)
external fuse
Infineon C167CR, 20 Mhz
576 Kbytes (Flash)
48 Kbytes (SRAM)
1536 bytes (FRAM)
128 bytes (FRAM)
53,4
46,4
CR1071 / page 1
17.09.2014
