PROCESS AND DIALOGUE MODULE

3. Mounting

■ Mounting accessories

The unit is supplied without mounting accessories.
Depending on the intended location and type of mounting the following mount-
ing accessories are available:
• EC1450, seal/vibration absorber for panel/control cabinet mounting
• EC1452, snap-in set for panel mounting*
• EC1453, fixing set for control cabinet mounting*
• EC1410...EC1414, RAM
You can find more information about the available accessories at:
www.ifm.com
*) Use the snap-in set (EC1452) and the fixing set (EC1453) only in conjunction
with the seal/vibration absorber (EC1450).

■ Seal/vibration absorber

Slide the seal/vibration absorber over the unit from the back.
22
PAGE
PDM 360
SMART
®
mount system for surface mounting
➔ Data sheet direct ➔ e.g. CR1070 ➔ Accessories
EC1450
Seal/vibration absorber for PDM360 smart,
PDM360 compact
the polyester film is
on the dialogue unit
